Features:
Impressive Image Clarity: At the heart of T3pro lies a detector with a resolution of 384×288, coupled with a pixel pitch of 17μm. This ensures every captured image is vivid and detailed. The Digital Detail Enhancement (DDE) takes this clarity up a notch, allowing you to distinguish even the subtlest temperature differences with ease.
Broad Temperature Coverage & Precision: Catering to a wide temperature spectrum ranging from -20℃ to +400℃, this device is not just versatile, but also incredibly precise. With an MRTD of ≤500mK and options for both manual and auto temperature correction, your readings are always spot on.
Advanced Analysis & Reporting: Beyond just imaging, the T3pro offers detailed temperature measurement statistics. Whether you need the maximum, minimum, or center temperature display or detailed point, line, or area analysis – this device has it all. What’s more, it even has built-in report functions, making data interpretation easy.
Seamless Integration & Expandability: Exclusively designed for Android users (6.0 and above), it’s a plug-and-play device. The secondary development kit (SDK) opens up avenues for custom applications, ensuring the T3pro grows with your needs.
Diverse Imaging Palettes & Updates: With multiple imaging palettes like White Hot, Black Hot, and other Pseudo Color options, customize your visual experience. Plus, the device is future-proofed with software update capabilities, ensuring you always have access to the latest features.
Specifications:
Model: T3pro
Detector Resolution: 384×288
Pixel Pitch: 17μm
Corresponding band: 8~14μm
Objective lens: 13mm
Focusing mode: Manual
Frame rate: 25Hz
MRTD: ≤500mK
Temperature range: -20℃~+400℃
Temperature correction: Manual/Auto
Power Consumption: <500mW
Weight (with lens): <40g
Size(with lens): 49.5×26×27.5MM
Support System: Android 6.0 and above
Image Enhancement: Digital Detail Enhancement (DDE)
Image Correction: Manual
Palette: White Hot/Black Hot/Multiple Pseudo Color Options
Secondary Development: Providing Secondary Development Kit (SDK)
Temperature Measurement Statistics: Support
Video Save: Support
Software Update: Support
Package Included:
1 x Thermal Imager
1 x USB Cable
1 x Bag
1 x User Manual
